DR1-D


Double multi-spring mechanical seal


Industrial | INDUSTRIAL INSTALLATIONS | CHEMICAL INDUSTRY | PHARMACEUTICAL INDUSTRY | MINING AND SLURRY INDUSTRY

Industrial | INDUSTRIAL INSTALLATIONS | CHEMICAL INDUSTRY | PHARMACEUTICAL INDUSTRY | MINING AND SLURRY INDUSTRY

Double multi-spring mechanical seal

  • Double multi-spring seal
  • Din 24960/EN12756
  • Independent direction of rotation
  • Pressure p = Vacuum/16 bar
  • Speed v=20m/s Max
  • Temperature t = -20+200°C

Seal designed in accordance with DIN 24960/EN12756, which can be used in a wide range of applications, particularly where fluids are not particularly viscous or prone to solidification. Used when the barrier fluid chamber is present in the device. In the DR1-HD version, the seal being balanced can withstand differential pressure values of 40 bar. For extreme applications, however, specific variations to the stated standards can be supplied.

The seal has undergone continuous evolution over time, enhancing its robustness and reliability. In particular, the torque drive on the rotary seal has been improved, which is in most cases in the Integral configuration.
In contrast to single-spring seals, multi-spring seals have a greater stress response and a more even load distribution.
∆P = pressure of the fluid to be contained - pressure of the barrier fluid.

AS PARTNER
MTU PROVIDING
YOU WITH THE
STATE OF ART
TECHNOLOGY.

We are able to offer a range of mechanical seals for the industrial sector, demonstrating a high level of versatility in its products. These items are designed and manufactured in-house by a team of highly specialised professionals who work constantly with customers to meet their needs.

This product can be used in the following sectors of intervention:
